DMM
Belay Master
Belay Master
Couldn't load pickup availability
Closing the clip on the Belay Master ensures the carabiner is safe for use. It can only be closed when the gate is screwed shut.
When closed, the clip keeps the carabiner in its strongest orientation, prevents devices and knots from moving onto the spine, eliminates possible cross loading due to rotation. This feature makes the Belay Master the perfect belay carabiner for those new to belaying.
Belay carabiner for consistent rope control and compatibility with belay devices
Belay carabiners give smooth and confident belaying with tube and assisted breaking belay devices. They have full section top bars for consistent rope control and reduced rope wear. Their shape resists flipping into sub-optimal orientations when belaying, acting to ensure the carabiner loads along its strongest axis.
Offset D carabiner for optimal loading and ergonomics
D-Shaped carabiners encourage loading in their strongest orientation by forcing loads toward the carabiner spine. An Offset D refines this basic design by extending the top bar, increasing internal volume. This improves handling and compatibility with thick ropes and slings.
Nylon clip ensures carabiner loads correctly
The Belay Master's nylon clip prevents accidental opening of the locking mechanism, and ensures the carabiner loads in its strongest orientation. This makes an ideal belay carabiner for new climbers.
Full section top bar for consistent rope handling and increased longevity
A rope running over a full section top bar has more consistent handling characteristics than one running over an I-Beam surface. Our belay carabiners feature full section top bars for greater control rope control. Ropes loading over full section bar also bend less than those loaded over I-Beam surfaces, increasing rope longevity.
Keylock nose eliminates snagging
This carabiner's nose slots into a groove in the gate, allowing it to achieve full strength without a gate notch. This creates a clean internal profile that won't catch on gear, bolts or slings, giving easier clipping and removal from systems.
I-Beam construction for optimum strength to weight ratio
I-Beam construction techniques allow carabiners to be lighter without compromising strength. This is achieved through hot forging, a process which allows metal to be made into complex shapes that improve functionality.
| Specifications | |
| Product | Belay Master |
| Colours | Titanium/Lime, Orange, Lime |
| Dimensions | 70 x 115mm |
| Weigth | 93g |
| MBS Major Access | 25kN |
| MBS Minor Access | 10kN |
| MBS Gate Open | 8kN |
| Gate Opening | 20mm |
| Certifications | EN 362:2004 B/T , EN 12275:2013 B & H |
